How To Read Data List
Required Special Tool:
MB991958: Scan Tool (MUT-III Sub Assembly)
- MB991824: Vehicles Communication Interface (V.C.I.)
- MB991827: MUT-III USB Cable
- MB991910: Main Harness A
CAUTION:
To prevent damage to scan tool MB991958, always turn the ignition switch to the "LOCK" (OFF) position before connecting or disconnecting scan tool MB991958.
- Connect scan tool MB991958 to the data link connector.
- Turn the ignition switch to "ON" position.
- Select "Interactive Diagnosis" from the start-up screen.
- Select "System select."
- Choose "IMMOBILIZER" from the "POWER TRAIN" tab.
- Select "Data List."
- Choose an appropriate item and select the "OK" button.
