Front Disc Brake Pads (Montero & Pickup): Installation

To install, reverse removal procedure. Press piston to bottom of caliper bore prior to pad installation. Ensure pad retaining clips are installed properly. See Fig 1 .

Fig 1: Installing Pad Retaining Clips Illustration applies to Montero and pickups.

Fig 2: Installing Spring & Clip on Brake Pads Illustration applies to Colt non-turbo models.
