(Remove front right wheel)
- If several wheels are removed simultaneously, mark each tire with a piece of chalk to show the axle and side on which the corresponding wheel is fitted.
- Release the lug bolts (arrows) and remove the wheel.
NOTE:
The following step(s) must be performed if the specified component(s) is/are installed.
- Use the appropriate adapter (2) from the set of special tools 0 492 518 (36 1 300) to detach and tighten wheel bolts with a locking wheel bolt (1).
NOTE:
Description is for left component only. Procedure on the right side is identical.
NOTE:
Schematic diagram is for example purposes. Some parts may differ in certain details.
- If several wheels are removed simultaneously, mark each tire with a piece of chalk to show the axle and side on which the corresponding wheel is fitted.
- Release the lug bolts (arrows) and remove the wheel.
NOTE:
The following step(s) must be performed if the specified component(s) is/are installed.
- Use the appropriate adapter (2) from the set of special tools 0 492 518 (36 1 300) to detach and tighten wheel bolts with a locking wheel bolt (1).
