Removing the wheel
WARNING:
Vehicle may slip off the vehicle hoist if the vehicle hoist is handled incorrectly.
Danger! Immobilization period-threatening injuries!
Danger! Immobilization period-threatening injuries!
- Observe safety instructions on raising the vehicle using a vehicle hoist.
- For additional information see: 00 02 001 RAISING THE VEHICLE WITH A VEHICLE LIFT (COUNTRYMAN 2017-2023, EXCEPT PHEV) .
NOTE:
TECHNICAL INFORMATION
During the installation of all four wheels (e.g. when changing from summer to mounted snow tires), the tire pressure must be checked!
During the installation of all four wheels (e.g. when changing from summer to mounted snow tires), the tire pressure must be checked!
Preliminary work
- If several wheels are removed simultaneously, mark each tire with a piece of chalk to show the axle and side on which the corresponding wheel is fitted.
- Release the lug bolts (arrows) and remove the wheel.NOTE: The following step(s) must be performed if the listed component(s) is/are installed.
- Use the appropriate adapter (2) from the set of special tools 0 492 518 (36 1 300)
to detach and tighten wheel bolts with a locking wheel bolt (1).
