51 75... Removing and installing/replacing tank cover on left or right

WARNING: This page is about a different car, the 2017 MINI Cooper, 2016 MINI Cooper, 2015 MINI Cooper, and 2014 MINI Cooper. However, it is still accessible from the selected car via links, so may be relevant.

Removal:

Right side:

Unscrew the screws (1).

Remove tank cover (2).

Fig 1: Locating Tank Cover And Screws (Right Side)

Courtesy of BMW OF NORTH AMERICA, INC.

Left side:

Unscrew the screws (1).

Remove tank cover (2).

Fig 2: Locating Tank Cover And Screws (Left Side)

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Right side:

Put on tank cover (2).

Tighten down screws (1).

Fig 3: Locating Tank Cover And Screws (Right Side)

Courtesy of BMW OF NORTH AMERICA, INC.

Left side:

Put on tank cover (2).

Tighten down screws (1).

Fig 4: Locating Tank Cover And Screws (Left Side)

Courtesy of BMW OF NORTH AMERICA, INC.
