63 99 451 Replacing light bulb for luggage compartment lighting

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2019 MINI Cooper, 2018 MINI Cooper, 2017 MINI Cooper, 2016 MINI Cooper, and 2015 MINI Cooper. However, it is still accessible from the selected car via links, so may be relevant.

WARNING: Follow SAFETY INSTRUCTIONS for handling light bulbs (interior lighting).

Necessary preliminary tasks:

Remove LUGGAGE COMPARTMENT LIGHT

NOTE: LED technology lights must be completely replaced.

Removal:

Release headlight lens cover (1) at latch mechanisms (2) on both sides.

Remove headlight lens cover (1) from luggage compartment light (3) in direction of arrow.

Fig 1: Removing Headlight Lens Cover From Luggage Compartment Light

G08514028

Courtesy of BMW OF NORTH AMERICA, INC.

Push out and remove the bulb (1) from the bulb socket with a suitable tool (e.g. screwdriver with 3 mm blade) in the direction of the arrow.

Fig 2: Removing Bulb From Bulb Socket With Suitable Tool

G08505941

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

NOTE: Note BULB TYPE .

Join the bulb (1) and the bulb socket in the opposite direction to the direction of the arrow.

Fig 3: Removing Bulb From Bulb Socket With Suitable Tool

G08505941

Courtesy of BMW OF NORTH AMERICA, INC.

Check headlight lens cover (1) before fitting.

If necessary, carefully press together both side tabs a little in direction of arrow.

Fig 4: Pressing Together Both Side Tabs

G11650124

Courtesy of BMW OF NORTH AMERICA, INC.

Join lens cover (1) to luggage compartment light (3) opposite to direction of arrow.

NOTE: Make sure lens cover (1) is correctly seated and engaged (2).

Fig 5: Removing Headlight Lens Cover From Luggage Compartment Light

G08514028

Courtesy of BMW OF NORTH AMERICA, INC.
