Replacing the transmission exhaust fan (6-speed, AISIN GA6F21AW)
WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2021 MINI Cooper, 2020 MINI Cooper, 2019 MINI Cooper, 2018 MINI Cooper, and 2017 MINI Cooper. However, it is still accessible from the selected car via links, so may be relevant.
Attention!
- Check exhaust fan for completeness after removal.
- Broken-off exhaust fan retaining lugs will result in serious damage to and failure of the automatic transmission.
- Never pull off the venting line at the transmission!
Necessary preliminary work:
- Remove VEHICLE BATTERY .
Removal:
Unscrew the screws (1).
Release vehicle battery partition wall (2) from holder and remove.
Release control unit (3) from holder
Detach wiring harness (4) from battery tray (5).
Remove battery tray (5).
Unscrew the screws (2).
Pull the exhaust fan (1) out of the exhaust fan line (3).
NOTE:
For vehicles from 01/2017 onwards, the bottom holder is not installed.
For vehicles up to 01/2017, the bottom holder (e.g. in the event of damage or loss) can be omitted and need not be installed.
For vehicles up to 01/2017, the bottom holder (e.g. in the event of damage or loss) can be omitted and need not be installed.
Installation:
Press the exhaust fan (1) into the exhaust fan line (3) up to the stop.
Tighten down screws (2).
Tightening torque 24 00 3AZ .
NOTE:
For vehicles from 01/2017 onwards, the bottom holder is not installed.
For vehicles up to 01/2017, the bottom holder (e.g. in the event of damage or loss) can be omitted and need not be installed.
For vehicles up to 01/2017, the bottom holder (e.g. in the event of damage or loss) can be omitted and need not be installed.
Install battery tray (5).
Tighten down screws (1).
Install wiring harness (4) on battery tray (5).
Insert control unit (3) in holder.
Insert vehicle battery partition wall (2) in holder.
Required follow-up work:
- Install VEHICLE BATTERY .
