Removing and installing/replacing 12-V power socket (Cooper Convertible)

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2021 MINI Cooper, 2020 MINI Cooper, 2019 MINI Cooper, 2018 MINI Cooper, and 2017 MINI Cooper. However, it is still accessible from the selected car via links, so may be relevant.

Special tools required:

61 0 250

Preliminary work needed:

Remove USB AUDIO INTERFACE CONNECTING SOCKET .

Front center console:

Disconnect the connector from the 12 V socket through the opening.

Remove 12 V socket using special tool. See last operation.

Courtesy of BMW OF NORTH AMERICA, INC.

Pull out 12-V power socket from housing with special tool 61 0 250 until connector is at bottom of light ring.

Courtesy of BMW OF NORTH AMERICA, INC.
