51 45 076 Replacing carrier for dashboard

When working on trim panel components, make sure that visible surfaces are not scratched or damaged (e.g. by sharp-edged tools).

Necessary preliminary tasks:

Release screws (2) from dashboard holder on passenger's side (1) on the inside and outside.

Set down both dashboard holders on passenger's side (1).

Fig 1: Identifying Screws And Dashboard Holder On Passenger Side

Courtesy of BMW OF NORTH AMERICA, INC.

Release screws (1) of air duct (2).

Remove air duct (2) and place to one side.

Pull off cold air duct (4) for glove box.

Unclip wiring harness (3) completely.

Fig 2: Identifying Air Ducts, Wiring Harness, And Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Unlock and disconnect plug connections (3) on Car Access System (1).

Set down wiring harness.

Release screw (4) of Car Access System (1) and set down Car Access System (1).

Unclip retaining bracket (2) of Car Access System and set down.

Remove remaining small parts from support.

Fig 3: Identifying Car Access System Plug Connections And Screws

Courtesy of BMW OF NORTH AMERICA, INC.
