25 11 007 Removing and installing gearshift bracket

WARNING: This page is about a different car, the 2016 MINI Cooper Paceman, 2015 MINI Cooper Paceman, 2014 MINI Cooper Paceman, and 2013 MINI Cooper. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary work:

Remove EXHAUST SYSTEM
Remove GEARSHIFT LEVER KNOB with gaiter

Remove heat shield (1).

Fig 1: Identifying Heat Shield

G04796697

Courtesy of BMW OF NORTH AMERICA, INC.

Release retaining clip (1).

Fig 2: Releasing Retaining Clip

G04796698

Courtesy of BMW OF NORTH AMERICA, INC.

Release screws (1).

Pull off shift lever housing (2) towards rear.

Fig 3: Identifying Shift Lever Housing And Screws

G04796699

Courtesy of BMW OF NORTH AMERICA, INC.

Installation note:

Front retaining lugs (1) of shift lever housing must first be fed into the vehicle underbody.

Fig 4: Identifying Front Retaining Lugs

G04796700

Courtesy of BMW OF NORTH AMERICA, INC.

IMPORTANT: Do not damage the bridges of the latch mechanisms on the lid.

Lift out the latch mechanism and release shift lever cover.

Fig 5: Locating Latch Mechanism And Shift Lever Cover

G11023341

Courtesy of BMW OF NORTH AMERICA, INC.

Installation note:

The bridges (1) of the latch mechanisms on the lid (2) must not be damaged.

Replace seals if defective.

Fig 6: Identifying Bridges Of Latch Mechanisms On Lid

G04796702

Courtesy of BMW OF NORTH AMERICA, INC.

Use suitable pliers to detach gear selector cable assemblies (1).

Remove clips (2) and pull gear selector cable assemblies out of housing.

Fig 7: Identifying Gear Selector Cable Assemblies And Clips

G04796703

Courtesy of BMW OF NORTH AMERICA, INC.
