51 13 375 Removing and installing/replacing cover on left or right rear roof pillar (D-pillar)

WARNING: This page is about a different car, the 2016 MINI Cooper Paceman, 2015 MINI Cooper Paceman, 2014 MINI Cooper Paceman, and 2013 MINI Cooper. However, it is still accessible from the selected car via links, so may be relevant.

Special tools required:

00 9 325

Necessary preliminary tasks:

Remove STRIP ON SIDE WINDOW

IMPORTANT: Risk of damage!
Ensure temperature equalization; covers which are too cold can be damaged when removed.
Position special tool 00 9 325 as closely as possible to clips (2) and lever out cover (1) with a short sharp jerk.

Fig 1: Positioning Special Tool (00 9 325)

Courtesy of BMW OF NORTH AMERICA, INC.

Installation note:

Replace faulty clips (1) on cover (3).

Replacement:

Modify holder (2).

Fig 2: Identifying Holder And Clips On Cover

Courtesy of BMW OF NORTH AMERICA, INC.
