84 10 700 Removing and installing/replacing base plate

Special tools required:

IMPORTANT: Read and comply with notes on PROTECTION AGAINST ELECTROSTATIC DISCHARGE (ESD PROTECTION) .

Feed out inserted mat (1) by approx. 5 cm at the front and rear and fold down.

Fig 1: Identifying Inserted Mat

Courtesy of BMW OF NORTH AMERICA, INC.

Fold center armrest up.

Lever out front shell (1) of cover toward front using special tool 00 9 325 .

Fig 2: Removing Front Shell Of Cover Using Special Tool (00 9 325)

Courtesy of BMW OF NORTH AMERICA, INC.

Fold center armrest down.

Lever out rear shell (1) of cover toward rear using special tool 00 9 325 .

Fig 3: Removing Rear Shell Of Cover Using Special Tool (00 9 325)

Courtesy of BMW OF NORTH AMERICA, INC.

Installation note:

Correctly lock retaining tabs of front (1) and rear (2) shell of cover.

Fig 4: Identifying Front And Rear Lock Retaining Tabs

Courtesy of BMW OF NORTH AMERICA, INC.

Carefully remove cover from support (1).

Installation note:

Make sure cover (1) is correctly seated.

Fig 5: Identifying Cover

Courtesy of BMW OF NORTH AMERICA, INC.

Release screws (1) and remove rear center console cover rearwards (2).

Fig 6: Identifying Rear Center Console Cover And Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Unlock plug connections (1) and disconnect.

Fig 7: Identifying Plug Connections

Courtesy of BMW OF NORTH AMERICA, INC.

Carefully lever out side cover (1) with special tool 00 9 327 .

Unfasten screws (2).

Fig 8: Removing Side Cover With Special Tool (00 9 327)

Courtesy of BMW OF NORTH AMERICA, INC.

Carefully lever out center armrest cover, top (1) with special tool 00 9 327 .

Remove center armrest cover top (1) with base plate (2) in direction of arrow.

Fig 9: Removing Center Armrest Cover With Special Tool (00 9 327)

Courtesy of BMW OF NORTH AMERICA, INC.

Carefully lever out base plate (1) with special tool 00 9 340 .

Fig 10: Removing Base Plate With Special Tool (00 9 340)

Courtesy of BMW OF NORTH AMERICA, INC.

Feed out cable (1) from center armrest (2).

Remove base plate (3).

Installation note:

Make sure the line routing of cable (1) is correct.

Fig 11: Identifying Cable, Center Armrest And Base Plate

Courtesy of BMW OF NORTH AMERICA, INC.
