54 61 006 Removing and installing (replacing) left or right rollover bar

Necessary preliminary tasks:

• Remove COVER ON PARTITION WALL AT TOP

Release screws (1).

Tightening torque 54 61 1AZ .

Lift out rollover bar.

Fig 1: Lifting Out Rollover Bar

Courtesy of BMW OF NORTH AMERICA, INC.

Replacement only:

Remove COVER ON ROLLOVER BAR .
