63 24 010 Removing and installing/replacing rear fog light (Cooper S)

Up to version 08/2010

Unlock retaining tabs (1) and simultaneously push rear fog light outward.

Disconnect plug connection and remove rear fog light.

Replacement:

Fig 1: Identifying Retaining Tabs

Courtesy of BMW OF NORTH AMERICA, INC.

From version 08/2010

Unfasten plug connection (1) and disconnect.

Release latch mechanisms (2) and remove rear fog light (3).

Replacement:

Fig 2: Identifying Rear Fog Light, Latch Mechanisms, And Plug Connection

Courtesy of BMW OF NORTH AMERICA, INC.
