11 31 025 Removing and installing or replacing intake camshaft (N18)

Special tools required:

IMPORTANT: It is absolutely essential to follow an exact procedure for dismantling and installing the intake camshaft.
In order to avoid incorrect timing setting, it is essential to check the locking of the camshaft adjuster and if necessary perform locking by rotating the camshaft.

Necessary preliminary work:

IMPORTANT: Check function of camshaft adjuster locking by rotating camshaft.

To release central bolts, always use special tool 11 7 440 of exhaust camshaft.

Position the special tool 11 7 440 at the mounting flats of the exhaust camshaft and fasten it with a screw (1).

Fig 1: Identifying Exhaust Camshaft Special Tool (11 7 440)
G09943809Courtesy of BMW OF NORTH AMERICA, INC.
IMPORTANT: Check function of camshaft adjuster locking by rotating camshaft.

Position the special tool 11 7 440 on the intake and exhaust camshaft and fasten it with screws (1).

To release central bolts, always use special tool 11 7 440 .

Fig 2: Positioning Special Tool (11 7 440) On Intake And Exhaust Camshaft
G09925597Courtesy of BMW OF NORTH AMERICA, INC.

Unfasten screws (2).

Remove tensioning rail (1).

Fig 3: Identifying Tensioning Rail And Screws
G04789810Courtesy of BMW OF NORTH AMERICA, INC.

Release screw (1).

Tightening torque: 11 11 3AZ .

Fig 4: Identifying Screw
G04796335Courtesy of BMW OF NORTH AMERICA, INC.

Release central bolt (1).

Tightening torque: 11 36 1AZ .

Place the VANOS unit onto the special tool 11 4 480 .

Remove EXHAUST CAMSHAFT .

Fig 5: Identifying VANOS Unit Central Bolts
G04796308Courtesy of BMW OF NORTH AMERICA, INC.
IMPORTANT: Removed cylinder head:
When using special tool 11 9 000 , it will be necessary to remove the aluminum strip.
IMPORTANT: The screw connection of the bearing bracket may not be loosened; Risk of damage.
Fig 6: Identifying Bearing Bracket Screws STOP Label
G04796273Courtesy of BMW OF NORTH AMERICA, INC.

Release all screws on the bearing cap (1 to 5).

Tightening torque: 11 12 7AZ .

All bearing caps (1 to 5) are identified with numbers from (6 to 9).

Set down all intake camshafts (6) on the special tool 11 4 480 in neat order.

Fig 7: Identifying Bearing Caps
G04796274Courtesy of BMW OF NORTH AMERICA, INC.

Plastic plain rectangular compression ring:

Plastic plain rectangular compression rings are already pre-installed on a new camshaft.

Plastic plain rectangular compression rings (1) are maintenance-free and must be replaced if damaged.

Insert plastic plain rectangular compression ring (1) into groove of intake camshaft (2) (see arrow).

Lightly oil plastic plain rectangular compression ring (1) and rotate in direction of arrow until plastic plain rectangular compression ring (1) is positioned on the intake camshaft.

Fig 8: Inserting Plastic Plain Rectangular Compression Ring Into Intake Camshaft Groove
G06907274Courtesy of BMW OF NORTH AMERICA, INC.

Check plastic plain rectangular compression ring (1 and 2) for freedom of movement.

Fig 9: Identifying Plastic Plain Rectangular Compression Rings
G06907275Courtesy of BMW OF NORTH AMERICA, INC.

Intake camshaft is identified with identification (IN).

Insert the intake camshaft so that the designation (IN) can be read from above.

Fig 10: Identifying Designations For Exhaust (EI) And Intake (IN) Camshafts
G04796268Courtesy of BMW OF NORTH AMERICA, INC.

Position the intake camshaft (E) so that cam of intake camshaft () points upward at an angle.

Installation note:

Lubricate all bearing positions with engine oil.

Fig 11: Identifying Intake Camshaft (E) Position
G04796270Courtesy of BMW OF NORTH AMERICA, INC.

Assemble engine.

Installation note:

Adjust VALVE TIMING .
