11 12 106 Removing and installing right cylinder head (N62 to 9 / 03): Installation:

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2005 BMW 745i, 2005 BMW 745Li, 2004 BMW 745i, 2004 BMW 745Li, and 2003 BMW 745i. However, it is still accessible from the selected car via links, so may be relevant.

Replace sealing ring.

Tightening torque of drain plug 11 11 5AZ. Refer to ENGINE - TIGHTENING TORQUES .

Top up coolant.

Vent cooling system and check for leaks. Refer to 17 00 039 VENTING COOLING SYSTEM AND CHECKING FOR LEAKS (N62) .

Remove ignition coils on cylinder bank 1 to 4.

Remove servomotor for right eccentric shaft.

Remove right cylinder head cover. Refer to 11 12 006 Removing and installing / sealing right cylinder head cover (N62 / N62TU) .

Remove intake air manifold. Refer to 11 61 050 Removing and installing intake air manifold (N62) .

Remove right timing case cover. Refer to 11 14 085 Removing and installing top right timing case cover (N62 / N62TU) .

Unfasten plug connection.

Place engine wiring harness to one side.

Remove spark plugs on cylinder bank 1 to 4.
