54 12 138 Removing and installing / replacing water channel for glass sliding/tilting sunroof: Notes
WARNING: This page does not describe the selected car, but rather 14 other vehicles, including the 2003 BMW 540i, 2003 BMW 525i, 2002 BMW 540i, 2002 BMW 525i, and 2001 BMW 540i. However, it is still accessible from the selected car via links, so may be relevant.
Removing and installing glass sliding/tilting sunroof lid, see 54 12 115 REMOVING AND INSTALLING GLASS SLIDING/TILTING SUNROOF LID
Move mechanism (1) to raising position.
Unclip water channel on left/right from setting lever (1) and remove from slide (2).
