63 99 131 Replacing bulb for left or right front parking light

WARNING: This page is about a different car, the 2003 BMW 530i, 2002 BMW 530i, and 2001 BMW 530i. However, it is still accessible from the selected car via links, so may be relevant.

WARNING: Follow instructions for handling light bulbs (exterior lights). Refer to 63 99... INSTRUCTIONS FOR HANDLING LIGHT BULBS (EXTERIOR LIGHTS) .

Disconnect plug connection (1).

Turn holder with side-marker lamp (2) in direction of arrow and remove.

Installation:

Make sure sealing ring is correctly seated.

Fig 1: Removing Holder With Side-Marker Lamp

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Note type of bulb, refer to LIGHTS - TECHNICAL DATA .
