51 47 101 Removing and installing/replacing luggage compartment floor trim(s)

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2008 BMW Z4, 2007 BMW Z4, 2006 BMW Z4, 2005 BMW Z4, and 2004 BMW Z4. However, it is still accessible from the selected car via links, so may be relevant.

Remove luggage compartment floor trim (1).

Also release clips (3).

Remove front luggage compartment floor trim (2).

Fig 1: Removing Front Luggage Compartment Floor Trim (2)

Courtesy of BMW OF NORTH AMERICA, INC.
