51 71 040 Removing and installing/replacing front left or right wheel arch cover

WARNING: This page is about a different car, the 2003 BMW 525i, 2002 BMW 525i, and 2001 BMW 525i. However, it is still accessible from the selected car via links, so may be relevant.

Remove front wheel.

M5 only:

Remove front splash guard.

Remove screws (1) and (2).

Fig 1: Removing Front Splash Guard

Courtesy of BMW OF NORTH AMERICA, INC.

Release expansion rivets (1) and (3).

Release screws (2).

Remove front wheel arch cover (4).

Installation:

Make sure front wheel arch cover is correctly seated against side wall.

Fig 2: Removing Front Wheel Arch Cover

Courtesy of BMW OF NORTH AMERICA, INC.
