17 11 040 Removing and installing/replacing thermostat insert for transmission oil cooling (M54)

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2006 BMW X5, 2006 BMW X3, 2005 BMW X5, 2005 BMW X3, and 2004 BMW X5. However, it is still accessible from the selected car via links, so may be relevant.

WARNING: Danger of scalding - this task may only be carried out once engine has cooled down.

Remove coolant expansion tank. Refer to 17 11 100 REMOVING AND INSTALLING/REPLACING COOLANT EXPANSION TANK (M54) .

NOTE: For purposes of clarity, this work step is shown on a removed expansion tank/mounting plate.

Pull coolant expansion tank (1) upwards out of mounting plate (3).

Fig 1: Removing Thermostat

Courtesy of BMW OF NORTH AMERICA, INC.

Pull thermostat insert (2) upwards out of connection piece.

Installation:

Check O-rings, replace if necessary.

Pay attention to turning lock when installing thermostat insert (2).
