11 12 111 Replacing Right Cylinder Head Gasket (N73)

WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2006 BMW 760i, 2006 BMW 760Li, 2005 BMW 760i, 2005 BMW 760Li, and 2004 BMW 760i. However, it is still accessible from the selected car via links, so may be relevant.

Cylinders 1 to 6.

Necessary Preliminary Tasks:

Remove right cylinder head. Refer to 11 12 106 REMOVING AND INSTALLING RIGHT CYLINDER HEAD (N73) .

IMPORTANT: Replace cylinder head gasket each time cylinder head is removed.

Check rubber coating (1) of cylinder head gasket for damage.

Installation:

Do not damage rubber coating (1) when fitting cylinder head.

Fig 1: Identifying Cylinder Head Gasket Rubber Coating (Right)

Courtesy of BMW OF NORTH AMERICA, INC.
