52 13 390 Removing and installing/replacing front headrest (normal/manual)

WARNING: This page is about a different car, the 2003 BMW X5, 2002 BMW X5, and 2001 BMW X5. However, it is still accessible from the selected car via links, so may be relevant.

Move backrest back.

Move headrest (1) as far upwards as possible.

Unlock lock (2) and remove headrest (1).

Fig 1: Locating Lock On Front Headrest

Courtesy of BMW OF NORTH AMERICA, INC.
