51 21 194 Removing and installing/replacing finisher from outside handle on left or right front door

WARNING: This page is about a different car, the 2002 BMW Z3 and 2001 BMW Z3. However, it is still accessible from the selected car via links, so may be relevant.

Unclip cover.

Fig 1: Removing Cover

Courtesy of BMW OF NORTH AMERICA, INC.

Push slide forwards with special tool 51 3 190 and remove finisher from outside handle.

Fig 2: Removing Finisher From Outside Handle

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Install finisher for outside handle, pull slide backwards with special tool 51 3 190 and ensure it is correctly engaged.
