51 14 110 Removing and installing/replacing model designation (emblem) at rear (Z3 roadster, M roadster)
WARNING: This page is about a different car, the 2002 BMW Z3 and 2001 BMW Z3. However, it is still accessible from the selected car via links, so may be relevant.
The model sign is glued and cannot be reused after removal. The model sign must be installed at room temperature.
Coat nylon string or thread with Tenside (e.g. dish detergent), cut through adhesive layer and remove with washing benzene.
At paint baking temperatures exceeding 80°C, the model designation must be removed.
Z3 Roadster:
Apply adhesive tape up to upper edge "A" and mark dimensions as per table.
Dimension in mm
A = 88, B = 30, C = 10.
