51 22 300 Removing and installing/replacing window cavity cover strip on rear door on left or right

WARNING: This page does not describe the selected car, but rather 19 other vehicles, including the 2010 BMW M5, 2009 BMW M5, 2008 BMW M5, 2007 BMW M5, and 2007 BMW 550i. However, it is still accessible from the selected car via links, so may be relevant.
IMPORTANT:

Observe PROCEDURE  for using special tool 00 9 324 .

IMPORTANT:

If reusing the existing window cavity cover strip (1), make sure it is not bent.

Lever out window cavity cover strip (1) with special tool 00 9 324 (starting at B-pillar).

Fig 1: Levering Out Window Cavity Cover Strip With Special Tool 00 9 324
G00460819Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Seal (1) must be correctly fitted in chrome strip (2).

Fig 2: Installing Seal
G04760997Courtesy of BMW OF NORTH AMERICA, INC.
