64 22 165 Removing and installing/replacing center fresh air grille

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2016 BMW 328i xDrive, 2016 BMW 328d xDrive, 2015 BMW 328i xDrive, 2015 BMW 328d xDrive, and 2014 BMW 328i xDrive. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Remove RIGHT DECORATIVE TRIM ON DASHBOARD

Replacement:

Carefully unlock retaining lugs in marked area.

Remove fresh air grille (2) from decorative trim (1) in direction of arrow.

Fig 1: Removing Center Fresh Air Grille

Courtesy of BMW OF NORTH AMERICA, INC.

Replacement:

Modify SWITCH FOR HAZARD WARNING SYSTEM/CENTRAL LOCKING
