61 62 090 Removing and installing/replacing shaft bearing for wiper arm

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2016 BMW 328i xDrive, 2016 BMW 328d xDrive, 2015 BMW 328i xDrive, 2015 BMW 328d xDrive, and 2014 BMW 328i xDrive. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Remove WIPER ARM FOR REAR WIPER

Secure rear window button (2) against falling down.

Release nut (1) and remove sealing ring underneath.

Tightening torque 61 62 2AZ .

IMPORTANT: Danger of water penetration. Always replaced micro-coated nut (1) and associated sealing ring. New sealing ring must not show any signs of damage.

Fig 1: Identifying Rear Window Button And Nut

Courtesy of BMW OF NORTH AMERICA, INC.

Remove caps (1).

Release nuts behind it and carefully remove wiper pivot bearing (2).

Tightening torque 61 62 3AZ .

Installation note:

Make sure wiper pivot bearing (2) is correctly fitted.

To facilitate installation, coat the rear-window button and wiper pivot bearing with lubricant (e.g. low-surface-tension water or G13*).

(*sourcing reference: BMW Parts Service)

Fig 2: Identifying Wiper Pivot Bearing And Caps

Courtesy of BMW OF NORTH AMERICA, INC.

IMPORTANT: Refer to the manufacturer's safety data sheet if using G13
