11 71 501 Remove and install/renew the exhaust-gas recirculation valve (EGR) (N47)

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2016 BMW 328i xDrive, 2016 BMW 328d xDrive, 2015 BMW 328i xDrive, 2015 BMW 328d xDrive, and 2014 BMW 328i xDrive. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Remove acoustic cover at front.
Remove SUCTION FILTER HOUSING .

Unlock vent line (2) and pull off to achieve improved freedom of movement of the exhaust-gas recirculation valve mounting.

Fig 1: Vent Line

Courtesy of BMW OF NORTH AMERICA, INC.

Release screws (1).

Lay positive battery cable to one side.

Fig 2: Positive Battery Cable Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Release screws (1) on exhaust-gas recirculation valve (3).

Release coolant lines (2 and 4).

Disconnect plug connection on exhaust-gas recirculation valve (3).

Installation note:

Install rear hose (2) before installing the exhaust-gas recirculation valve.

Replace O-ring.

Fig 3: Exhaust-Gas Recirculation Valve And Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Assemble engine.

Check function of DDE.
