66 33 008 Removing and installing/replacing park assist control unit

WARNING: This page does not describe the selected car, but rather 27 other vehicles, including the 2017 BMW M6, 2017 BMW 650i xDrive, 2017 BMW 650i, 2017 BMW 640i xDrive, and 2017 BMW 640i. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Remove LUGGAGE COMPARTMENT STORAGE COMPARTMENT

NOTE: Only with 24V steering:

Unscrew nuts (1).

Take off holder (2).

Move the auxiliary battery (3) out of the working area.

Fig 1: Identifying Auxiliary Battery, Holder And Nuts

Courtesy of BMW OF NORTH AMERICA, INC.

Release plastic nuts (1).

Remove control unit holder (2) from tail panel trim.

Remove park assist control unit (3) from holder (2).

Unlock plug connection (4) and disconnect.

Remove the Parking assistant control unit (3).

Fig 2: Identifying Park Assist Control Unit, Holder, Plug Connection, And Plastic Nuts

Courtesy of BMW OF NORTH AMERICA, INC.

Replacement:

Carry out PROGRAMMING/ENCODING .
