61 31 233 Removing and installing/renewing Lane Departure Warning engine electrical system (TLC actuator)

WARNING: This page does not describe the selected car, but rather 27 other vehicles, including the 2017 BMW M6, 2017 BMW 650i xDrive, 2017 BMW 650i, 2017 BMW 640i xDrive, and 2017 BMW 640i. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Remove airbag unit. See REMOVING AIRBAG UNIT or REMOVING AIRBAG UNIT (SPORT STEERING WHEEL) .
Remove lower steering wheel trim

Disconnect plug connection (1).

Release screws (2) and remove engine electrics (3).

Tightening torque 32 33 2AZ .

Installation note:

Replace screws (2).

Ensure correct cable routing.

Fig 1: Identifying Engine Electrics, Plug Connection And Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Replacement:

From version 03/2009 onwards, the engine electrical system must be adjusted.

For the adjustment, the resonance frequency stamped on the actuator is required. Note the resonance frequency of the new part.

The service module "Adjustment actuator Lane Departure Warning" can be found at:

Body
Camera-based driver support systems
Adjustment of lane departure warning actuator
