52 17 034 Removing and installing/replacing shaft for headrest adjustment (comfort seat)

WARNING: This page is about a different car, the 2003 BMW X5 and 2002 BMW X5. However, it is still accessible from the selected car via links, so may be relevant.

Headrest must be moved as far forwards as possible.

Remove rear panel at top.

Remove rear panel at bottom.

Withdraw shaft in succession from gear and drive.

Installation:

Carry out function check.

Fig 1: Removing Headrest Adjustment Shaft

Courtesy of BMW OF NORTH AMERICA, INC.
