51 12 223 Removing and installing/replacing trim for rear bottom middle bumper trim

WARNING: This page is about a different car, the 2010 BMW X6. However, it is still accessible from the selected car via links, so may be relevant.

Version with trailer tow hitch: Release screws (1) and remove tow hitch flap (2).

Unclip trim (3) all round from bumper trim.

Fig 1: Identifying Trim, Tow Hitch Flap And Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Installation note:

Catches (1) and guides (2) on trim (3) must not be damaged.

Fig 2: Identifying Trim, Guide And Catches

Courtesy of BMW OF NORTH AMERICA, INC.

M model only:

Release screws (1) and remove trim (2).

Fig 3: Identifying Trim And Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Installation note:

Catches (1) and guides (2) on cover (3) must not be damaged.

Fig 4: Identifying Trim Cover, Guide And Catches

Courtesy of BMW OF NORTH AMERICA, INC.
