3.11 Fixing the window glass

WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2016 BMW 760Li, 2015 BMW 760Li, 2014 BMW 760Li, 2013 BMW 760Li, and 2012 BMW 760Li. However, it is still accessible from the selected car via links, so may be relevant.
Fig 1: Supporting Window Glass Using Plastic Adhesive Tapes And Special Tool (51 3 210)
G08472015Courtesy of BMW OF NORTH AMERICA, INC.

Fix the window glass with yellow plastic adhesive tapes (2).

Immediately remove dirt contamination with adhesive residue using Sika remover 208. Do not press out the window glass again.

Hardened adhesive can only be removed mechanically.
