67 61 007 Removing and installing/replacing drive with gearbox (rear) for actuating slide/tilt sunroof (rear)

WARNING: This page is about a different car, the 2011 BMW 750xi, 2011 BMW 750Lxi, 2010 BMW 750xi, and 2010 BMW 750Lxi. However, it is still accessible from the selected car via links, so may be relevant.

IMPORTANT: Read and comply with notes on PROTECTION AGAINST ELECTROSTATIC DISCHARGE (ESD PROTECTION) .

Necessary preliminary tasks:

Lower HEADLINING

Disconnect plug connection (1) and if necessary expose cable.

Release screws (2) and remove drive (3).

Tightening torque 54 13 1AZ .

Fig 1: Identifying Drive, Plug Connection And Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Installation note:

Insert gear (1) of electric motor with gearbox for operation of slide/tilt sunroof (2) exactly in gearing (3).

Fig 2: Identifying Gear, Actuating Slide/Tilt Sunroof And Gearing

Courtesy of BMW OF NORTH AMERICA, INC.

Installation note:

INITIALIZE slide/tilt sunroof.
