61 33 060 Removing and installing/replacing both fanfare horns

WARNING: This page is about a different car, the 2005 BMW 545i and 2004 BMW 545i. However, it is still accessible from the selected car via links, so may be relevant.

Release screws (1).

Detach cover (2) from front underride protection (3) and feed out in direction of arrow.

Remove cover (2).

Fig 1: Removing Cover From Front Underride Protection

Courtesy of BMW OF NORTH AMERICA, INC.

Unlock plug connections (1) and disconnect.

Release nuts (2) and remove fanfare horns (3).

Fig 2: View Of Fanfare Horns

Courtesy of BMW OF NORTH AMERICA, INC.
