17 00... Instructions for repair work on cooling system: Recycling
WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2010 BMW 335xi, 2010 BMW 335i, 2009 BMW 335xi, 2009 BMW 335i, and 2008 BMW 335xi. However, it is still accessible from the selected car via links, so may be relevant.
Catch and dispose of drained coolant.
Observe country-specific waste disposal regulations.
NOTE:
To disconnect coolant hoses, use commercially available disconnect tools such as HAZET brand tools (see table).
| HAZET no.: | Designation |
|---|---|
| 4590-1 | Disconnect-pliers, length (mm): 150 |
| 4590-2 | Disconnect-pliers, length (mm): 180 |
| 4590-3 | Disconnect-pliers, length (mm): 253 |
| 4590 / 2 | Disconnect-plier set |
| 4590 / 3 | Disconnect-plier set |
NOTE:
Tightening torque for hose clamps
| WAF 5 | 1.0 - 1.5 Nm |
| WAF 6 | 2.5 - 3.5 Nm |
Instructions for dismantling/assembly of coolant hose quick-release couplings
