51 16 000 Removing and installing/replacing mirror on left or right front door: Replacement

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2012 BMW 328xi, 2012 BMW 328i, 2011 BMW 328xi, 2011 BMW 328i, and 2010 BMW 328xi. However, it is still accessible from the selected car via links, so may be relevant.

Due to the thread-tapping screws, the tightening torque of the new mirror is increased by 2 Nm.

Tightening torque 51 16 1AZ .

Fig 1: Identifying Plug Connection And Screws

Courtesy of BMW OF NORTH AMERICA, INC.

Remove mirror (1) outwards.

Installation:

Check function.

Fig 2: Removing Front Mirror

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Acoustic insulation (1) must not be damaged.

Fig 3: Identifying Acoustic Insulation

Courtesy of BMW OF NORTH AMERICA, INC.
