Necessary preliminary tasks

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2012 BMW 328xi, 2012 BMW 328i, 2011 BMW 328xi, 2011 BMW 328i, and 2010 BMW 328xi. However, it is still accessible from the selected car via links, so may be relevant.

E83 only:

Remove window cavity cover strip on outside of front door

Partially detach rubber window seal (1) at rear.

Fig 1: Disconnecting Rubber Window Seal

G04767890

Courtesy of BMW OF NORTH AMERICA, INC.

Release screws (1).

Remove finisher (2) and press approx. 3 mm towards rear.

Fig 2: Removing Finisher

G04767891

Courtesy of BMW OF NORTH AMERICA, INC.

Remove trim (1) towards top.

Fig 3: Removing Trim

G04767892

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Following parts must not be damaged or missing:

Plastic nuts
Sound insulation
Seal

Fig 4: Identifying Sound Insulation, Seal And Plastic Nuts

G06978874

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Check trim (1) for damage, replace if necessary.

Fig 5: Identifying Trim

G04788691

Courtesy of BMW OF NORTH AMERICA, INC.
