Necessary preliminary tasks

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2012 BMW 328xi, 2012 BMW 328i, 2011 BMW 328xi, 2011 BMW 328i, and 2010 BMW 328xi. However, it is still accessible from the selected car via links, so may be relevant.

Remove REAR SPOILER

Prerequisite:

REAR LID must be correctly adjusted

Slacken nuts (1) on left/right, do not release fully

NOTE: Rear window height is adjusted by inserting shims (2).

Fig 1: Identifying Shims And Nuts

Courtesy of BMW OF NORTH AMERICA, INC.

Adjust rear window (1) in accordance with GAP DIMENSIONS and secure in place with nuts (2).

Tightening torque 51 31 1AZ .

If necessary, adjust REAR WINDOW WIPER MOTOR .

If necessary, adjust REAR WINDOW LOCK .

Fig 2: Adjusting Rear Window

Courtesy of BMW OF NORTH AMERICA, INC.
