Necessary preliminary tasks

WARNING: This page does not describe the selected car, but rather 8 other vehicles, including the 2012 BMW 328xi, 2012 BMW 328i, 2011 BMW 328xi, 2011 BMW 328i, and 2010 BMW 328xi. However, it is still accessible from the selected car via links, so may be relevant.

Remove COVER FOR CAPPING on right
Remove LUGGAGE COMPARTMENT TRIM ON SIDE PANEL on right
Remove FRONT TRIM FOR LUGGAGE COMPARTMENT FLOOR

Release screws (1).

Release expansion rivets (2).

Lever out trim (3) in direction of arrow and remove.

Release screw (4) and remove trim (5).

Feed out luggage compartment wheel arch trim in inwards direction.

Fig 1: Identifying Screws, Rivets And Trim

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Guides (1) and catches (2) on trim (3) must not be damaged.

Fig 2: Identifying Guides And Catches On Trim

Courtesy of BMW OF NORTH AMERICA, INC.
