24 11 010 Removing and installing/sealing or replacing transmission sump (GA6HP26Z) (N63): Installation

WARNING: This page does not describe the selected car, but rather 19 other vehicles, including the 2015 BMW Alpina B7L, 2015 BMW Alpina B7, 2014 BMW Alpina B7L, 2014 BMW Alpina B7, and 2013 BMW Alpina. However, it is still accessible from the selected car via links, so may be relevant.

The gasket is correctly installed when it is engaged in the locating opening of the transmission sump.

Fig 1: Identifying Gasket Of Transmission Sump

Courtesy of BMW OF NORTH AMERICA, INC.
