13 63 590 Replacing fuel pump relay

WARNING: This page is about a different car, the 2003 BMW X5, 2002 BMW X5, 2001 BMW X5, and 2000 BMW X5. However, it is still accessible from the selected car via links, so may be relevant.

Interrogate fault memory of DME control unit.

Switch off ignition.

Remove right glovebox.

Release screws (1).

Remove fuse box (2) towards bottom (do not disconnect electrical connections).

Fig 1: Removing Fuse Box

Courtesy of BMW OF NORTH AMERICA, INC.

Detach fuel pump relay (1).

After removal of fuel pump relay and during engine starting sequence:

the fuel pump no longer starts up,
the engine does not start.

Fig 2: Detaching Fuel Pump Relay
Courtesy of BMW OF NORTH AMERICA, INC.

NOTE: Interrogate fault memory of DME control module.

Check stored fault messages.

Rectify faults.

Then clear fault memory.
