Individual parts, switch for passenger airbag deactivation

WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2014 BMW X6, 2013 BMW X6, 2012 BMW X6, 2011 BMW X6, and 2010 BMW X6. However, it is still accessible from the selected car via links, so may be relevant.

Fig 1: Identifying Passenger Airbag Deactivation Switch Components

G06212551

Courtesy of BMW OF NORTH AMERICA, INC.

Necessary preliminary tasks:

Remove switch for passenger airbag deactivation , see 61 31 038 REMOVING AND INSTALLING (REPLACING) SWITCH FOR PASSENGER AIRBAG DEACTIVATION .

Release screws (1).

Remove housing cover (2) and PCB (3) underneath.

Fig 2: Identifying Housing Cover And PCB

G04749693

Courtesy of BMW OF NORTH AMERICA, INC.

Remove switch unit (1) in upward direction.

Installation:

Switch unit (1) can only be installed in one position.

PCB (4) can be inserted turned through 180°.

Position of magnet sensor (3) of PCB (4) must match up with permanent magnet (2) of switch unit (1).

Fig 3: Identifying Magnet Sensor, PCB, Permanent Magnet And Switch Unit

G04749694

Courtesy of BMW OF NORTH AMERICA, INC.

Remove guide (1) in upward direction.

Installation:

Guide (1) can only be installed in one position.

Fit seal (2) on guide (1) and insert in switch housing.

Fig 4: Identifying Seal And Guide

G04749695

Courtesy of BMW OF NORTH AMERICA, INC.

IMPORTANT: Ignition key must be inserted in lock cylinder, otherwise this will be destroyed when removed.

Insert ignition key in lock cylinder (2).

Carefully release catches (1) in outward direction and press out lock cylinder (2) with ignition key.

Installation:

Lock cylinder (2) can only be inserted in "ON" or "OFF" switch position.

Lock cylinder

Fig 5: Identifying Catches And Lock Cylinder

G04749696

Courtesy of BMW OF NORTH AMERICA, INC.
