51 16 040 Removing and installing/replacing housing on left or right exterior mirror

WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2014 BMW X6, 2013 BMW X6, 2012 BMW X6, 2011 BMW X6, and 2010 BMW X6. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Remove mirror glass, see 51 16 026 Replacing mirror glass for rear-view mirror (on front door) .

NOTE: Housing (2) is secured without play by four multitooth catches (1) on retaining ring (3).
Secure housing on exterior mirror (2) against falling out.

Unlock multitooth catches (1) with a screwdriver.

Unclip housing (2) forwards from retaining ring (3) and remove.

Fig 1: Identifying Housing, Retaining Ring And Multitooth Catches

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Multitooth catches (1) and guide (2) on housing (3) must not be damaged.

Fig 2: Identifying Multitooth Catches, Guide And Housing

Courtesy of BMW OF NORTH AMERICA, INC.

Installation:

Locators (1) on retaining plate (2) must not be damaged.

Fig 3: Identifying Locators And Retaining Plate

Courtesy of BMW OF NORTH AMERICA, INC.
