Bowden cable, right

WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2014 BMW X6, 2013 BMW X6, 2012 BMW X6, 2011 BMW X6, and 2010 BMW X6. However, it is still accessible from the selected car via links, so may be relevant.

Release union nut (1).

Installation:

Tightening torque 34 41 5AZ . See 34 41 PARKING BRAKE .

Fig 1: Identifying Union Nut

G06211844

Courtesy of BMW OF NORTH AMERICA, INC.

Pull Bowden cable (1) out of actuating unit (2).

Fig 2: Identifying Bowden Cable And Actuating Unit

G06211845

Courtesy of BMW OF NORTH AMERICA, INC.

Unlock locking sleeve (1) and pull out of housing a little.

Fig 3: Unlocking Locking Sleeve

G06211846

Courtesy of BMW OF NORTH AMERICA, INC.

Snap out coupling (1) in direction of arrow.

Fig 4: Removing Coupling

G06211847

Courtesy of BMW OF NORTH AMERICA, INC.

After installation:

Carry out initial operation/function test in BMW diagnosis system.

Path

Function selection
Service functions
Chassis
Parking brake
Initial operation/function test
