51 22 300 Removing and installing/replacing window cavity cover strip on rear door on left or right

WARNING: This page is about a different car, the 2010 BMW M3, 2009 BMW M3, and 2008 BMW M3. However, it is still accessible from the selected car via links, so may be relevant.

Special tools required:

00 9 324

See MAINTENANCE AND GENERAL INFORMATION - SPECIAL TOOLS .

IMPORTANT: Observe procedure for using special tool 00 9 324 .

The " Instructions on fitting window guide seals " serve as the basis for this repair instruction and must be observed without fail.

Necessary preliminary tasks:

E91 only:

Remove trim on window frame at rear

IMPORTANT: If reusing the existing window cavity cover strip (1), make sure it is not bent.

Lever out window cavity cover strip (1) with special tool 00 9 324 (starting at B-pillar).

Feed window cavity cover strip (1) at rear out of guide (2).

Installation:

Moisten window cavity cover strip (1) prior to fitting with approved anti-friction agent.

Window cavity cover strip (1) must be flush at front and rear with door edge.

Fig 1: Identifying Window Cavity Cover Strip

Courtesy of BMW OF NORTH AMERICA, INC.

Version with Chromeline:

Installation:

If chrome strip (2) has been pulled out of cover strip (3), both parts must be reassembled.

Feed guide (1) of chrome strip (2) into groove (3) of window cavity cover strip (4).

Replacement:

Window cavity cover strip (4) and chrome strip (2) are replaced completely.

Fig 2: Identifying Window Cavity Cover Strip And Chrome Strip

Courtesy of BMW OF NORTH AMERICA, INC.
