26 11 160 Replacing constant-velocity joint for propeller shaft

WARNING: This page is about a different car, the 2010 BMW M3, 2009 BMW M3, and 2008 BMW M3. However, it is still accessible from the selected car via links, so may be relevant.

Special tools required:

See FRONT AXLE - SPECIAL TOOLS .

Necessary preliminary tasks:

Lever sealing cap (1) with screwdriver (2) out of constant-velocity joint (3).

NOTE: Replace sealing cap (1) with seal.
Fig 1: Removing Sealing Cap
G06204807Courtesy of BMW OF NORTH AMERICA, INC.
NOTE: Installation sequence:
  1. Constant-velocity joint
  2. Seal
  3. Sealing cap
Fig 2: Identifying Constant-Velocity Joint And Seal With Sealing Cap
G06204808Courtesy of BMW OF NORTH AMERICA, INC.

Lift off retainer

Installation:

Replace circlip.

Fig 3: Locating Circlip
G06204809Courtesy of BMW OF NORTH AMERICA, INC.

Force cap off constant velocity joint.

Installation:

Insert sealing washer (1) into constant-velocity joint.

Fig 4: Inserting Sealing Washer Into Constant-Velocity Joint
G06204810Courtesy of BMW OF NORTH AMERICA, INC.

Detach constant-velocity joint (1) with special tool 26 1 110  and commercially available special tool (2).

Fig 5: Detaching Constant-Velocity Joint With Special Tool
G06204811Courtesy of BMW OF NORTH AMERICA, INC.

Release clamp (1) and detach cap with gaiter.

Push on new cap with gaiter.

NOTE: Do not tighten down clamp (1) yet.
Fig 6: Detaching Cap With Gaiter
G06204812Courtesy of BMW OF NORTH AMERICA, INC.

Mount constant-velocity joint with special tool 23 1 160  up to stop.

Align bores of constant velocity joint and cap to each other.

Tighten down clamp on gaiter.

NOTE: Keep toothing free of grease.

Inject new grease into constant velocity joint from rubber gaiter and flange sides.

Fig 7: Identifying Special Tool (23 1 160)
G06204813Courtesy of BMW OF NORTH AMERICA, INC.
NOTE: Prepare special tools 31 2 102  and 31 2 104  .
Fig 8: Identifying Special Tool (31 2 104 And 31 2 102)
G06204814Courtesy of BMW OF NORTH AMERICA, INC.

Press sealing cap with special tools 26 1 121  , 26 1 122  , 31 2 102  and 31 2 104  into constant-velocity joint (1).

NOTE: Align sealing cap and seal to bores of constant-velocity joint with screw.
Fig 9: Pressing Sealing Cap With Special Tools
G06204815Courtesy of BMW OF NORTH AMERICA, INC.

Push cap (1) onto constant-velocity joint (2).

Fig 10: Pushing Cap Onto Constant-Velocity Joint
G06204816Courtesy of BMW OF NORTH AMERICA, INC.
