61 62 090 Removing and installing/replacing shaft bearing for rear window wiper (Touring)

WARNING: This page does not describe the selected car, but rather 6 other vehicles, including the 2010 BMW 535xi, 2010 BMW 535i, 2009 BMW 535xi, 2009 BMW 535i, and 2008 BMW 535xi. However, it is still accessible from the selected car via links, so may be relevant.

Necessary preliminary tasks:

Remove REAR WINDOW WIPER ARM
Remove TRIM ON SHAFT BEARING

Secure rear window button (2) against falling down.

Release nut (1) and remove sealing ring underneath.

IMPORTANT:

Risk of water ingress. Always replaced micro-coated nut (1) and associated sealing ring. New sealing ring must not show any signs of damage.

Tightening torque 61 62 7AZ .

Fig 1: Identifying Window Button And Nut

Courtesy of BMW OF NORTH AMERICA, INC.

Release nut (1) and withdraw shaft bearing (2).

Installation:

Tighten nut (1) to specified torque, tightening torque 61 62 1AZ .

Fig 2: Identifying Shaft Bearing And Nut

Courtesy of BMW OF NORTH AMERICA, INC.
