65 77 560 Removing and installing/replacing control electronics for passenger seat occupancy detector
WARNING: This page does not describe the selected car, but rather 7 other vehicles, including the 2010 BMW X3, 2009 BMW X3, 2008 BMW X3, 2007 BMW X3, and 2006 BMW X3. However, it is still accessible from the selected car via links, so may be relevant.
Necessary preliminary tasks:
- Move seat into most upward position
- Unlock and remove first aid kit under passenger seat
NOTE:
Seat removed for purposes of clarity.
Turn control electronics for passenger seat occupancy detector (2) approx. 45° in direction of arrow and unclip from seat frame.
Disconnect plug connections (1) and remove control electronics for passenger seat occupancy detector (3).
